picture, ok, contrast, ok, 9, 7, 3, 5
RECORD
Chassis H-501, H-501V PEKOPD XANTRAX 51/54TTS5168 51/54TTS5169 Proc. Z8624704PSC
login - Need to consistently push the button on the remote.
(DISPLAY) (MUTE) (SLEEP) (FUZZY)
Further, when pressing the DISPLAY button made adjustment of geometry and AGC, and when you press SLEEP - white balance.
output - POWER OFF
Chassis ST-201 14/51/54 TTS5169 51/54TTS5172 Proc. STV9424 80S31
login
- Must hold at the front of the TV buttons (menu), and (CH +) to
include a network switch. Then take the TV out mode STAN-BY usual way.
Next, pull up the menu on the screen.
output - POWER OFF
Chassis G-1000 51/54 TTS5171 Proc. MC44002 MC44140
login
- You must disable inc. "Network" and then turn it back on while
holding the button on the toolbar (P +) and (P). On the screen at the
bottom of the letters will appear GLHPRGB A. Active mode is highlighted
in yellow. Mode switching from the control book. (Menu) setting (P +)
(P-) (G-) Set U to CRT varies on strochnike. The display will show a red
or green square. Need to install so that they both went out.
output - POWER OFF
Chassis SC-18 (PAEX0088)
37/51/54TTS5177 51/54TTS5168 51/54TTS5176 TS-2076/2176 54TTS5172
TS-2172 Control Processor: TMP87CK38N Video Processor: TD1238N
There are three service modes: S, D, M.
S-Mode - the service;
D-mode - extended service;
M-mode - expedited + training.
Log in to the service S-mode adjustment (SERVICE MODE) with a conventional remote control:
in
the operating mode of the TV, press and hold the button on the front
panel VOL-(volume at minimum position), press the button on the remote
DISPLAY.
In the upper left corner of the TV screen will appear the symbol S is the inclusion of a special regime of service regulation.
Selection of a new function by pressing the button on the remote control or PROG + PROG-.
Adjusting the value of the function by pressing the remote button VOL + or VOL-.
When
pressed on the remote control button on the screen disappears -/--
Frame Scan. From the emission of a narrow horizontal band to adjust the
accelerating voltage.
The values of the controlled functions are stored in memory automatically.
Log in to service mode D, M possible only with a special service remote control.
TV returns to normal operation after turning off the network and then on again.
output POWER OFF
addition:
TD-1918 chassis PAEX0021 PAEX0045 ST-223 entry into the advanced D-service mode
1.B
operating mode, the TV turn the volume down to 0 value, then press and
hold the button on the front panel VOL-, press the button on the remote
DISPLAY (while the TV goes in the S-service mode).
2.Otpustit in
front of the TV button VOL-, press the button on the remote DISPLAY.
Repeatedly press the TV front panel VOL-button, and again press the
DISPLAY (in this case the TV should go into service mode D - extended
service).
Chassis ST-208, 209 TC-1466, TC-2066S, TC-2166S, TC-2068S, TC-2168S Processor Control: MTV212MS64U Video Processor: TDA8842
Login
the service mode adjustment (SERVICE MODE) with conventional remote
control: in standby mode, press the TV series on the remote control
button, MUTE, AV, MENU, POWER.
In the main user menu there is a new line - SERVICE.
To enter a basic service menu, press the remote button VOL +.
Adjusting the value of the function by pressing the remote button VOL + or VOL-.
Selection of a new function by pressing the button on the remote control P + or P-.
output - POWER OFF
RECORD 54TTS5188 Processor: ST92185BN2B1/EUA TV2KV Ver.4.511, OSD processor: MTV018N24-35, video processor: STV2246 X43
login
in service: Press the remote control button hidden under the "P-"
circuit panel SD3331AD (findings 8 and 17) Menu Design - go to Tools and
click "OK".
chassis-TV2K 37/51/54 TC 5188 Control Processor: ST92185. Video Processor: STV2246
Login
in service mode (SERVICE MODE) is possible with the modified remote
control (RC) (Remove the top cover PDU.1. break the window in the bottom
of the cover under the green button remote SERVISE (click entry into
the service mode). 2.Install formed in window of any button, not having
much practical value, pre-cut it. 3. Collect the remote.) press the
SERVICE, on your TV screen, a menu appears SERVICE V2.0.
Exit - SERVICE
Chassis ST-210 RECORD 51TTS5175, 37/51/54TTS5173 Processor Control: MTV212MS64U Video Processor: TB1238Z
Login the service mode adjustment (SERVICE MODE) with the usual console remote.
In standby mode, press the TV series on the remote control button, MUTE, AV, MENU, POWER.
In the main user menu there is a new line - SERVICE.
To
enter a basic service menu, press the remote button VOL + Adjust the
value of the function by pressing the remote button, VOL-or VOL +
Selection
of a new function by pressing the button on the remote control P + or
P-values of the controlled functions are stored in memory
automatically.
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:15 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الجمعة مايو 06, 2011 5:25 pm
PEKOPD 51/54 TC 5169 (Chassis ST-201)
To
access the menu to hold on the TV front panel buttons (Menu) and (CH +)
to include a network switch. Then take the TV out mode STAND-BY in the
usual way. Next, pull up the menu on the screen.
PEKOPD xx TC 5171 (chassis G-1000)
CPU MC44002, MC44140
Turn
off on "network" and then turn it back on while holding the button on
the toolbar (P +) and (P-). On the screen at the bottom of the letters
will appear GLHPRGB A. Active mode is highlighted in yellow. Mode
switching from the control book. (Menu) setting "P +", "P". G - Set U on
kinescope, ranging in strochnike. The display will show a red or green
square. Need to install so that they both went out.
PEKOPD xx TTS5169 51/54TTS5172 (Chassis ST-201)
Processor STV9424 80S31
Hold
the front of the TV buttons (menu), and (CH +) to include a network
switch. Then take the TV out mode STAN-BY usual way. Next, pull up the
menu on the screen.
PEKOPD chassis H-501
To
enter the service menu should consistently press the button on the
remote control - (DISPLAY) (MUTE) (SLEEP) (FUZZY). Further, when
pressing the DISPLAY button made adjustment of geometry and AGC, and
when you press SLEEP - white balance.
RECORD 51TTS5175, 37/51/54TTS5173 (Chassis ST-210)
Video Processor: TB1238Z
Processor MTV212MS64U
Log in to the service adjustment mode (SERVICE MODE) with a conventional remote control console.
In standby mode, press the TV series on the remote control button, MUTE, AV, MENU, POWER.
In the main user menu there is a new line - SERVICE.
To enter a basic service menu, press the remote button VOL +
Adjusting the value of the function by pressing the button on the remote control VOL-or VOL +
Selection of a new function by pressing the button on the remote control P + or P-
The values of the controlled functions zapisyvabtsya in memory automatically.
RECORD 54TTS5188
Processor: ST92185BN2B1/EUA TV2KV Ver.4.511
OSD processor: MTV018N24-35
Video Processor: STV2246 X43
Service: Press the remote control button hidden under the "P-"
Integrated circuit remote SD3331AD (findings 8 and 17)
Menu Design - go to Tools and click "OK".
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:33 pm
RECORD
CHASSIS 200-100-TV2K. Record 37/51/54 TC 5188.
Video Processor: STV2246.
Control Processor: ST92185.
Enter the service mode (SERVICE MODE) is possible with the modified
Remote Control (RC) circuit modifications described below (page 2).
Log in SERVICE MODE with the modified remote control: press the SERVICE, the on-screen
TV menu appears SERVICE V2.0.
Moving the cursor over the lines produced by pressing P +, P-.
Change the value of the controlled parameter is performed using the buttons? -, +.
Schedule of main menu SERVICE MODE:
setting the level description
Tuner A.G.C. 46 automatic level control
Red gain control 38 red to white (accelerating)
Red cutoff control 32 red in black
Green gain control 38 in White Green
Green cut-off control 32 green in the black
Blue gain control 38 are blue in the White H
32 Position the horizontal offset (phase)
VPOS 50 07 centering on a vertical (50 Hz)
VPOS 60 08 centering on a vertical (60 Hz)
VAMP 50 40 vertical size (50 Hz)VAMP 60 48 vertical size (60 Hz)
VCO Coarse adjustment of the drive 05
VCO Fine adjustment of the inverter 070
VCO Coarce L1 adjustment drive 05 for L-standard
VCO 080 control IF 2
Fine L1 for the L-standard
To enter the service menu in the attached press on the remote click OK.
Schedule submenu SERVICE MODE:
setting the level description
A.G.C. AGC Gain 01
Misc February 1 OPTION BYTES not change!
Misc 2 00 OPTION BYTES
Misc 3 00 OPTION BYTES
HPOS OSD OSD positioning 009
VPOS OSD 01 OSD positioning
HPOS TXT * 046 is not used in the model
HVPOS TXT * 05 is not used in the model
VHF / UHF Note 1
Crystal
3,58 Mhz NO
* - Only for models with teletext. Note 1: for PAL BG = VHF models
for PAL I = UHF models
SCHEME MODIFICATIONS RC
[ندعوك للتسجيل في المنتدى أو التعريف بنفسك لمعاينة هذه الصورة]
CHASSIS FOR 200-100-TV2K
1. Remove the top cover of the remote control.
1. Break the window in the bottom of the cover under the green button remote SERVISE
(Click entry into the service mode).
2. Set in a window formed any button, not having a large practical value, pre-cut it.
3. Collect remote.
3
Enter the service mode:
Press the green button SERVICE
Adjust the accelerating voltage is as follows:
place the cursor in the main service menu on line Red Gain, in
bottom of the TV screen scale "G2 status";
Turn the accelerating voltage set at TDKSe
"G2 status" in position "OK".
Setting the drive as follows:
conclusions 10, 11 SLE connect the signal cable IF (38.9 MHz, 50 mV).
When connecting the cable to make sure that the conclusion 11 can be connected
Signal output cable, and to pin 10 - body;
place the cursor in the main service menu on line VCO FINE 070.
Tuning coil L208 before the inscription "AFC Status OK";
pressing the "-" on the remote control to find the lower limit of the range set IF (disappears inscription "OK" .
Then press the "+" button on the remote control and increase the value of VCO FINE 5
units. Move the cursor to the VCO Coarce - must be established 05 and illuminates the inscription "OK".Exit service mode:
Press the green button SERVICE
Adjustment in service mode
a) To enter the service mode button on the remote control, set Service
M mode or press the sequence of buttons menu-pp-8-5-0-0.
b) Press the 0-9 section, select the desired service menu (menu 0 - Menu 9).
In the SERVICE can be accessed from a universal remote code MAK 2002 maxi 1269
OK, the screen red letter M.
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:03 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:34 pm
Chassis G-mode TV 1000.Servisny "Record 51/54 SC 5169/5171"
(MCU ST6365BB1/BLM, video MC44002P)
To enter service mode turn off the TV power switch,
while pressing and holding down the P + and P-in front panel
TV. Then include a TV, while continuing to hold down
P + and P-for at least three seconds. At the bottom of the screen should
receive an image service menu. A list of options available
for adjustment, is shown in Table. 9.
Table 9
Parameter Parameter description
G accelerating voltage
L Vertical LinearityV Vertical Size
H Horizontal centering (phase)
R White Balance in the "bright"
G White Balance in the "bright"
B White balance in the "bright"
A Adjusting AGC
Necessary to adjust the parameter selected the MENU button on the remote control and
regulate the content keys P + and P?. After moving to the next
setting a new value is automatically saved.
To exit the service mode, press the TV button on the remote.
(MCU Z8624704PSC, video STV2118B)
To enter the service mode with the remote service has consistently pressed
buttons F1 - F2 - F3. If there is no remote service, then perform this operation
for normal remote control: it has consistently pressed the button DISPLAY - MUTE -
SLEEP - FUZZY - SLEEP (or DISPLAY). You should see a list of parameters (Table 7).
Navigation on the list - by pressing CH +, CH-, and adjusting the selected
setting - with the buttons - and +.
Table 7
Parameter Parameter description
V POS Vertical Alignment
V HEIGHT Vertical Size
H SHIFT Horizontal Alignment
SUB BRT SubyarkostAGC Automatic Gain Control
R DRV white balance "light"
G DRV white balance "light"
B DRV white balance "light"
R DC White Balance in the "dark"
G DC White Balance in the "dark"
HEAT RUN mode of training
To exit the service menu again click on the buttons in series
F1, F2, F3 on the service remote control or turn off the TV power switch and then on again.
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:04 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:36 pm
CHASSIS PAEX0045. D - Service mode (20 ", 21"
addition to the service bulletin 12, entry into the extended D-service
Mode 1. In operating mode, the TV turn the volume down to 0
value, then press and hold the button on the front panel VOL-,
press the button on the remote DISPLAY (in this case goes to TV S-service mode).
2. Release the front of the TV button VOL-, press the button on the remote DISPLAY.
Then press on the front of the TV button and VOL-again
press DISPLAY (with the TV should switch to a service
Mode D - extended service).
Use the opportunity to overwrite values set in memory so-called "processor failures" (eg, spontaneous initialization, zeroing established
values).
CHASSIS ST-201.Servisny TV mode "Record 51/54 SC 5169/5172"
(MCUs SAB80C32, M27C256B or STV9224, video STV2118B)
To access the menu to hold the front of the TV
MENU key and turn the CH + network switch. Then take
TV from the STAND-BY mode the usual way.
Next, pull up the menu on the screen.
To enter service mode turn off the TV, simultaneously press
and hold the MENU button and PR +, located on the front of the TV.
Then turn off again and include a TV, while still holding the button for three seconds.
MENU button is released and PR + and click on the buttons PR +, PR-(on the front panel
TV or on the remote). Press the MENU button, and moving on
appears on-screen service menu (see Table Cool, using the buttons
PR + and PR-select the option you want and adjust its buttons -
and +. To exit the service mode, turn off the TV network
and switch on again.
Table 8
Parameter Parameter description
V POC Vertical Alignment
V H Vertical Size
HS centering horizontally
SUB BRT Subyarkost
SUB CTR Subkontrastnost
R DRV white balance "light"
G DRV white balance "light"
B DRV white balance "light"
R DC White Balance in the "dark"
G DC White Balance in the "dark"
CHASSIS ST-208, 209. XANTRAX TC-1466, TC-2066S, TC-2166S, TC-2068S, TC-2168S
(A list of service codes)
1. XANTRAX TC-1466, TC-2066S, TC-2166S, TC-2068S, TC-2168S (Chassis ST-208, 209)
Video Processor: TDA8842 Processor Control: MTV212MS64U
Enter the service mode adjustment (SERVICE MODE) with a conventional remote control:
in standby mode, press the TV series on the remote control button, MUTE, AV, MENU, POWER.
In the main user menu there is a new line - SERVICE.
To enter the basic service menu, press the button on the remote control VOL +.
Adjusting the value of the function by pressing the remote button VOL + or VOL-.Selection of a new function by pressing the button on the remote control P + or P-.
Schedule of Basic Tools:
SCREEN - Reg. Display Settings
CATHODE - Reg. Modes of cathodes
TUNING - the choice of parameters Tuner
SCR - subnasyschennost
OSD Pos. - Adjustment of the OSD on
Horizontal
SCREEN, CATHODE, TUNING have their own sub-sub-menu.
Schedule sub SCREEN:
FUNCTION VALUE DESCRIPTION
H SHIFT 31 Horizontal Alignment
V SHIFT 31 Vertical Alignment
V SIZE 31 Size Vertical
V SLOPE 31 Vertical Linearity
S CORR 31 S-correction
Schedule sub CATHODE:
FUNCTION VALUE DESCRIPTION
R 31 R in black
G 31 G in black
B 31 B in black
SBT 31 Subyarkost
SCT 31 Subkontrastnost
FUNCTION VALUE DESCRIPTION
AGC AGC 31
CTT 5020E 38.9 Selecting the type of tuner
In this scheme can be used the following types of tuners:
UV1316 / S I2 38.0
UV1316 / S I2 38.9
CTT5020E 38.0
CTT5020E 38.9
IF is automatically adjusted when choosing a type of tuner.
The values of the controlled functions are stored in memory automatically.TV returns to normal operation after turning off the network and then on again.
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:05 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:38 pm
RECORD 51TTs5175b 37/51/54TTS5173 (Chassis ST-210)
Video Processor: TB1238Z
Control Processor: MTV212MS64U
Enter the service mode adjustment (SERVICE MODE) with a conventional remote control remote.
In standby mode, press the TV series on the remote control button, MUTE, AV, MENU, POWER.
In the main user menu there is a new line - SERVICE.
To enter the basic service menu, press the VOL + button remote control
Adjusting the value of the function by pressing the button on the remote control or the VOL-VOL +
Selection of a new function by pressing the button on the remote control P + or P-
The values of the controlled functions are stored in memory automatically.
RECORD 54TTS5188 processor: ST92185BN2B1/EUA TV2KV Ver.4.511
, OSD processor: MTV018N24-35, video: STV2246 X43
Service: Press the button on the remote control hidden under the "P-"
Chip control SD3331AD (findings 8 and 17)
Menu Design - enter the service and click "OK"
CHASSIS SW-216AP, SW-1411SP, SW-2013AP. Service mode TV "Record 37/51/54 SC 5169"
(MCU SW-1222AP - R3602, video TDA8374)
To enter the service mode with remote control service include a TV in
operating conditions and subsequently click the button on the remote control SLEEP - FACTORY.
With a staff entrance at the remote service mode is only possible after its
refinement. Revised scheme for remote chassis SW-216AP and SW-1411SP shows
Fig. 1, a chassis for SW-2013AP - Fig. 2.
[ندعوك للتسجيل في المنتدى أو التعريف بنفسك لمعاينة هذه الصورة]
Fig. 1. Revised scheme for full-time remote chassis SW-216AP and SW-1411SP
Note.
1. Refinement of the regular remote control according to Fig. One is to remove the links
(Rupture of the tracks) in two places on the circuit board and the installation of three new bridges.
2. Refinement of the regular remote control according to Fig. 2 is set in place
Button Factory one of the seldom-used keys (eg, CH.SCAN or
LANGUAGE). This button is neatly excised from the rubber matrix of buttons.
To enter the service mode with the modified remote control (Fig. 1) consistently
click on the button, it SLEEP - CH.SCAN. If RC modified according to Fig. 2
then to enter service mode press the FACTORY. You should
display the main menu service mode (Table 4).
Navigation in the main and nested menu buttons running P +, P-and OK
(To enter the selected menu) on the remote control, and control settings - buttons -,
+. The new values are saved
automatically after switching to another parameter.
Table 4
Main Menu Description
ADJUSTMENT menu to adjust your audio and video
TEST PATTERN display mode of the field test RGB
OPTION BYTE control processor configuration management
2
RESET System reset (set to Factory Default)
To set up the TV mode, "PAL / SECAM, 50 Hz" is fed to its input
corresponding signal in the menu ADJUSTMENT regulate the parameters given in Table. 5.
Table 5
The full name of the parameter description of the parameter
AGC Auto gain control Automatic gain control
VCO Auto fine tune the support contour-Video Set
SBT Sub bright Subyarkost
SCT Sub contrast SubkontrastnostSCR Sub color Subnasyschennost
SC S-cor. vert. S-correction in the vertical
RG R drive gain white balance "light"
GG G drive gain white balance "light"
BG B drive gain white balance "light"
CDL Color delay delayed chrominance signals
PSL PAL slope vert vertical linearity
PVS PAL vert. Centering on a vertical shift
PVA PAL vert. Amplitude Vertical Size
PHS PAL horiz. The alignment shift horizontally
To set up the TV mode "NTSC, 60 Hz," serves at its input
corresponding signal in the menu ADJUSTMENT regulate the parameters given in Table. 6.
Table 6
The full name of the parameter description of the parameter
AGC Auto gain control Automatic gain control
VCO Auto fine tune the support contour-Video Set
SBT Sub bright Subyarkost
SCT Sub contrast Subkontrastnost
SCR Sub color Subnasyschennost
SC S-cor. vert S-correction in the vertical
RG R drive gain white balance "light"
GG G drive gain white balance "light"
BG B drive gain white balance "light"
NSL NTSC slope vert vertical linearityNVS NTSC vert. Centering on a vertical shift
NVA NTSC vert. amplitude Vertical Size
NHS NTSC horiz. The alignment shift horizontally
The menu OPTION BYTES set configuration parameters specific model of TV.
Byte options 1 and 2, in hexadecimal, respectively, are 8 and 99.
RESET menu allows you to set the factory settings.
To exit the service mode, press the button on the remote CH.SCAN.
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:07 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:39 pm
CHASSIS SW-216M. TV Service Mode "Record 51/54 TC 5169"
(MCU
SW-1222APR or SMZ-137M3 - 2558, M52777SPA video)
To enter the service mode on this chassis can be used as a service
Remote Control (RC) and staff (the user).
In the first case include a TV in the working mode, and remote service
Repeatedly press SLEEP - FACTORY. In the second case, the normal
Repeatedly press the remote control STAND-BY - P. STD - HELP - SLEEP - POWER
ON. The screen should display the main menu service mode (Table 1).
Navigation in the main and nested menu buttons running P +, P-and OK
(To enter the selected menu) on the remote control, and control settings - buttons -
and +. New settings are automatically saved after move to another setting.
Table 1
Main Menu Description
ADJUSTMENT menu to adjust your audio and video
TEST PATTERN display mode of the field test RGB
OPTION BYTE control processor configuration management
RESET System reset (set to Factory Default)
To set up the TV mode, "PAL / SECAM, 50 Hz" is fed to its input
corresponding signal in the menu ADJUSTMENT regulate the parameters given in Table. 2.
Table 2
The full name of the parameter description of the parameter
AGC Auto gain control Automatic gain control
SBT Sub bright Subyarkost
SCT Sub contrast Subkontrastnost
SCR Sub color Subnasyschennost
PDL PAL delay adjustment delays chrominance signals in PAL
RC R cut off White balance in the "dark"
GC G cut off White balance in the "dark"
BC B cut off White balance in the "dark"RG R drive gain white balance "light"
BG B drive gain white balance "light"
PSL PAL vert. Centering on a vertical shift
PVS PAL slope vert vertical linearity
PVA PAL vert. amplitude Vertical Size
PHS PAL horiz. The alignment shift horizontally
To set up the TV mode "NTSC, 60 Hz," serves its input signal and the corresponding
ADJUSTMENT menu regulate the parameters given in Table. 3.
Table 3
The full name of the parameter description
AGC Auto gain control Automatic gain control
SBT Sub bright Subyarkost
SCT Sub contrast Subkontrastnost
SCR Sub color Subnasyschennost
STT Sub tint delayed in NTSC color signal
NDL NTSC delay AGC
RC R cutoff white balance "dark"
GC G cutoff white balance "dark"
BC B cutoff white balance "dark"
RG R drive gain white balance "light"
BG B drive gain white balance "light"
2
NSL NTSC slope vert centering on a vertical
NVS NTSC vert. The linearity of the vertical shift
NVA NTSC vert. amplitude Vertical SizeNHS NTSC horiz. The alignment shift horizontally
The menu OPTION BYTES set configuration parameters specific model of TV.
Byte options 1 and 2 in hexadecimal are, respectively, 1C and 42.
RESET menu allows you to set the factory settings.
To exit the service mode, turn off the TV power switch and then on again.
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:08 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:41 pm
CHASSIS TD-18. XANTRAX TC-2172S
1. XANTRAX TC-2172S (SC-18 chassis)
Video Processor: TD1238N
Control Processor: TMP87CK38N
There are three service modes: S, D, M.
S-mode - a service;
D-mode - extended service;
M-mode - crash + training.
Enter the service mode adjustment S-(SERVICE MODE) with a conventional remote control:
Working in TV mode, press and hold the front panel
button VOL-(volume in the minimum position), press the button on the remote DISPLAY.
In the upper left corner of the TV screen will appear which means the inclusion of S
special mode of service regulation.
s
name and the value of the TV screen adjustable functionSelection of a new function by pressing the button on the remote control or PROG + PROG-.
Adjusting the value of the function by pressing the remote button VOL + or VOL-.
The list of controlled functions in S-mode service.
When you press the remote button on the screen disappears -/-- Frame Scan. On
the glow of a narrow horizontal band to adjust the accelerating voltage.
The values of the controlled functions are stored in memory automatically.
Enter the service mode D, M is possible only with a special service remote control.
TV returns to normal operation after turning off the network and
reclosing.
Record xx TC 5171
First we need to turn off the TV button "network" and then again
turn it on while holding the button on the panel "P +" and "P". On the screen at the bottom
of letters will appear GLHPRGB A. Active mode is highlighted in yellow
color. Switching modes from a control book. "Menu" option "P +", "P"
G - Set U to the picture tube, varies in strochnike. The display will show
red or green square. You need to install so that they both went out.L - Vertical Linearity
H - Vertical Size
P - Horizontal Shift
R, G, B - white level
And - it is not clear why.
SIT - 405
Enter the service mode for the SIT-405 can be made at any state
TV from AV mode as well as from any channel. To enter the necessary
have in place control the RS-4 with a button SERV. In the absence of the buttons can be
connect the button between the legs 15 and 23
(HL1) chip in the console. When you press the SERV not less than 0.5 seconds
the display will light up the SIT-405 CH (CHEK) is a so-called scanning mode
TV. This mode does not prevent normal operations for the TV. Distinction
differs in that the accelerated automatic repetition of commands from the panel SIT-405
(Synthesizer strains). This feature is very handy when testing the TV.
It allows you to quickly set up your TV to a channel, and allows fast
change control: brightness, contrast, saturation and volume.
If you press the SERV again, the display will light up the PR and we get to the mode OPTIONS.This mode allows you to tune the processor in accordance with SAA1293
the capabilities of your TV or on the user.
I advise all to sketch what you see on the screen before you start changing settings
SAA1293. After entering the OPTIONS to select the switching between menu items.
As we wrote above for the chip must be -02 to click SERV, and for
03 to be pressed on the VOL +. On display will be displayed in turn 4
submenu. In each sub-menu to 9 options (along with a point). When the irradiated segment
value is 1 (yes) with braised segment 0 (none).
The figure indicated the segments with their corresponding key on the keypad. The table
which is located below, you can see what the value of the segment which corresponds to the team.
[ندعوك للتسجيل في المنتدى أو التعريف بنفسك لمعاينة هذه الصورة]
Note: An explanation of some options.
1.6 If the TV has a confirmation tone and matches (APCHG), then
controller can use two additional properties:a) Timer switch the TV into standby mode after 5 minutes after the end of TV programs.
b) When approaching the station at the time of setting automatically switches
speed settings from coarse to fine, which the user is not
will miss the station, setting it at a higher rate.
3
These two properties can not be separated, because their work depend on
voltage on pin 28 of microprocessor. When a signal is the voltage
2.8 - 12 Volts. when there is no signal - 0.8 volts.
2.2 If this option is selected, all four analog control for
off from standby are both at startup. Otherwise, they are normalized.
2.3 In selecting this option button, the band does not occur immediately
after pressing, and after 5 seconds. Or, when pressed repeatedly.
3.3 This option specifies the version of the procedure memory. If this option is not selected,
then option A, but if you choose a version of B.
Option A:
1. Selects the desired standard.
2. Selects the desired range.3. When you set up the station selected indicator shows the range and flicker,
APCHG off and stays off.
4. MEM allows key for 5 seconds to select the desired channel (two flicker
segment). If the selection time is over, it is not stored and the indicator
will show the number previously selected channel. The values of the analog adjustments
not saved. Save them in the MEM mode, you must press "Normalization"
or any of the eight analog.
Option B:
Selects the desired standard.
Selects the desired range.
In the settings for the selected station APCHG off and is turned over after 1 sec
squeezing the key settings.
Selects the desired channel.
MEM button saves all the parameters of the station and analog values. In this
version no time limit and control the analog fixed together
the setting. To read them you must press "normalization."
Here are the most frequently used combinations of these options.
From practical experience I know that to start the firmware chip memory in
MSN home synthesizers voltage-405 is best with a 4 th sub-menu.
And also after the introduction of firmware (changing field segments) to be pressed
on the M button on the front of the TV. Otherwise, all changes
on-chip memory remain unchanged.
* * *
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:09 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:42 pm
TV REKORD CT2108PF,
microprocessor
TDA9381PS/N3/2/1830, was replaced successfully by NTDA79381-7NA.ot
TV AKAI (do not remember the model) Entry into the service menu:
former press MENY and quickly dial 8-5-0-0, bust menyushek 0-9. Exit from the menu ST-BY.
* * *
RECORD TV CT-2197K,
Processor: TDA9381PS/N2/3102.
Entering the service menu: home in the remote button is hidden, left and below V +.
M appears in the menu nine sections - buttons on the remote rooms
channels from first to ninth - in the section on options P + P-, options to change V +. V-
Exit from service - a hidden button and off TV. RC-5 is not necessary.
* * *
TV ROLSEN C21SR80NT,
Firmware
Rolsen NTP2.1g TDA9352PS/N3/1/1683, Sekam, Pal, DK, KSH148O.
Entering the service menu: press> St-by> the MENU button on
TV + 0 on the remote. Exit> TV.
* * *
TV RECORD 51TTS5175 (ST-210shassi).
Percent. management.: MTV212MS64U, Videoprots: TV1238Z.
Entering the service menu: press the standby mode
consistently buttons on the remote MUTE, then AV, then MENU,
and the last POWER. In the main user menu there is a new line - SERVICE.
To enter service in the basic menu, press VOL + button on the remote.
Adjusting the functions performed by pressure button VOL + or VOL-on the remote.
Selection is made by pressure of another function keys P + or P-on the remote.
* * *
Record TV CT-2103.
Sought information on accessing the service menu: But it turned out
that there is no console in the shops, either on the market. Wriggled way
next - enter the service mode and adjust the two consoles can do: "Samsung" AA59-10075K, and "LG" 6170v00090F.
On the panel on "LG" click the OK button in the upper left corner
display the letter M appears in the submenu buttons move
switching programs 9.Perebor 0 items submenu, using
panel from the "Samsung", buttons P +, P-, change quantities keys V +, V-.
At the end of the remote service adjustments "LG" press
Double button and click OK button Power, that is, adjust the record.
Obviously, this method is suitable for all models with
Microprocessor TDA9381/PS/N3/2/1973, in reference specified. And also
and that entry into the service menu and adjust the panels can do, "sister" named.
* * *
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:10 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:44 pm
TV Roadstar LCD7114KL.
ZD7.820.426 chassis. Microprocessor M37160MAH-069FP.
Enter the service mode: The original remote requires control and MAC 2005 with the code 3203.
Apparatus in the mode of working with the IAC-st we press the button AV
(Below the second row, from left to the extreme), the screen lights at the top left of the inscription in red letters TEST.
On the remote press MUTE original and we are in the service menu.
Pages service menu the same button MUTE turn over
on the remote. Management buttons CHANNEL and VOLUME. Saving to memory - on the remote POWER OFF.
* * *
TV Rolsen D29R55,
CPU
TDA9365PS/N3/5, memory 24C16W6, audio processor MSP3410G B8 V3, tuner KSH148E.
Entering the service menu:-menu + 0 on the TV. Exit-TV
* * *
TV Rubin 55FM10-8
microprocessor
NTDA9381C323A, 24S08W6 memory.
Entering the service menu: TV transfer mode
duty, then, holding down the "Menu" button on
front panel push button TV remote control 0.
* * *
TV ROLSEN 32D60D,
and other types of RL-32x20.
Entering the service menu: press the button consecutively:
DISPLAY, then 1, then 1, then LINE.
* * *
TV ROLSEN C2119.
Processor labeled
CH08T0934-5H32-3K49 on the concept TMR87SM38N, memory
24S08 (24S04), video TB1238AN, remote SC9028-023, HR TA8403K, FBT BSC62T.
Log into the service menu without the remote service can be as follows:
1. Set the volume equal to "0". (Necessarily)
2. click "MUTE" button on the holding, "MENU" button to click on the front panel of the TV.
3. in the right corner of the screen, the letter "D" light up, and
left in a corner of the controlled parameter and its value will be
displayed.
Switching between the red and green buttons made, yellow and blue buttons to change settings on a blue field.
Exit from the menu service to the conservation of modifications in the parameters of buttons "Stand-by" button on the remote.
* * *
TV ROLSEN C2119. C2116.
Log in to the remote home.
Enter the menu service: the following is possible:
volume equal to "O", install it. (immutable)
Button "MUTE" click on the remote
click "MUTE" holding, "MENU" button to click on the front panel.
Illuminates the letter "D" on the screen in the right corner and left
corner of the controlled parameter and its value will be displayed.
To switch between produced red and green
control buttons on a blue field. Changing the values of parameters are on a blue field with yellow and blue buttons.
* * *
TV Rolsen C2135.
Log into the service menu: The S2135 can enter with an ordinary remote control.
We must console open, pad, closest to the chip,
a button is drawn. If you close it, the TV will go into service mode.
* * *
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:12 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:46 pm
TV ROLSEN C17R80 Plat.
Menu like apparatus
LG, the entrance to the service menu: Standby mode while holding the MENU button on the TV, push button "0" on the remote user.
You get the inscription IF 38.9 or IF 38.0, movement on the menu
buttons to switch programs, control parameter values
buttons adjust the volume. To exit the service menu,
to the TV or AV press, all the changes at the same time in the EEPROM are written.
* * *
TV Rolsen 100 Hz models: (C29R140, C29R142, C29R100, C29R148).
Remote service at 100 Hz Rolsen made from any
RC-5 compatible (based on the chip, 3010). Log into the service menu (sell order):
SVC 1.nadavit button on the remote service for half a second (or at the same time, close contacts 1 and 11)
2. push the button "Ok" button.
* * *
TV ROLSEN C2150Z.
Microprocessor
TDA9381PS/N3/1/1730 CD8681 P1FTE 20 ROLSEN FM 2.Oc. 24C08 EEPROM. Transformer line PET22-23C.
LG menu is similar, the entrance to the service menu: the volume to "0"
set, turn off the TV in standby mode, press and
hold the button down (V +) on the unit, then click
"0" press on the remote control, hold down the button until the
ignition until the brightness of the LED is not green will grow.
The screen will be IF 38.0 inscription, save settings button on the remote control TV / AV ...
* * *
TV ROLSEN C2170 Plat.
Control processor TDA9381PS/N3/1/1730.
Enter the service mode in the mode of the standby button to push MENU
button on the TV, and 0 on the remote, the preservation of the unit's
settings.
* * *
TV Roadstar LCD7114KL.
ZD7.820.426 Chassis for M37160MAH-069FP.
Entering the service menu: need original remote control and MAC 2005 with code 3203.
Apparatus in the mode of working with the IAC-th click on the button AV (bottom
second row, left to the extreme), on the screen at the top left of the inscription
TEST red letters light up.
On the remote press MUTE original and we are in service. Pages service
turn over to the control of the same buttons MUTE. Management buttons
CHANNEL and VOLUME. In memory of the remote-POWER OFF.
The option values:
11 V SIZE ---------------- 0
10 V SHIFT -------------- 1
13 V60 SHIFT ----------- 1
12 T SIGNAL ----------- 0
15 LCD LEVEL --------- 0
14 V60 SIZE ----------- 58
17 M61266 28H ------ 255
16 M6126X -------------- 0
19 M61266 2AH ----- 255
18 M61266 29H ------ 255
21 CG-------- ---------- 125
20 CR-------- ---------- 125
23 DR-------- ----------- 63
22 CB-------- ---------- 125
25 SB-------- ---------- 127
24 DB-------- ----------- 63
27 FM BAND ----------- 0
26 SC-------- ------------ 15
29 -------------------------1
28 FM WAIT TIME --- 25
31 FM INPUT ----------- 1
30 OP POWER ---------- 0
33 BLACK LEVEL --- 35
32 BACKGROUND ---- 1
35 LOGO ON ----------- 0
34 DISPLAY--- --------- 2
36 LOGO INPUT ----?
38 FM IF SET ----------- 0
37 FM ADCL MIN ---- 50
40 VIF VCO ADJ ------ 26
39 FM-------- ------------- 0
42 VIDEO OUTGAIN-7
41 RF DELAY ADJ ---- 66
44 BLACK ST OFF ----- 0
43 OM DET -------------- 0
46 BLACK ST GAIN --- 1
45 BLACK ST ADJ ----- 6
48 TAKE OFF --------- 1
47 Y DL ---------------- 6
49 TRAP FINE ADJ-3
51 SUB TINT TV ----- 65
50 SUB COLOR ----- 60
53 BASE BRI ---------- 4
52 SUB TINT AV ---- 65
55 MON------- ---------- 1
DVD ----------------- 1 54
57 S TRAP -------------- 7
56 GAMMA----- ------- 3
59 VIF FREQ ----------- 1
58 ATT------- --------- 127
* * *
عدل سابقا من قبل أشرف عثمان في الخميس يوليو 21, 2011 5:13 pm عدل 1 مرات
الرجوع الى أعلى الصفحة اذهب الى الأسفل
أشرف عثمان
المدير العام
المدير العام
عدد المساهمات: 2242
تاريخ التسجيل: 16/06/2010
العمر: 53
مُساهمةموضوع: رد: سرفس مود - RECORD الخميس يوليو 21, 2011 4:47 pm
TV RUBIN 72FDS109.
Entering the service menu: push on the button [PRESET],
then [TEST] remote service, on-screen in the upper right corner
the letter M will appear. To exit the service, the service
remote press [TEST]. Can also be accessed from the service mode, pressing the button [STANDBY].
Entering the service menu with the remote user: button
push [MENU], appears on the menu "Image".
Push button digital [6] [4] [8] [3] on the remote. Toto enter into service menu M1 ~ M4, corresponding to pressure
digital button on the remote. To enter the service M5 ~ M0,
must first press the [CALL] key to exit the M1-M4 menu
appears on the letter M, then press the button consecutively
[LOCK] (Figure suitcase with a handle) and one of the buttons digital
[5] to [9] and [0] to enter the menu M5 ~ M0. If you are in any of the menu
M5 ~ M0 are, then move to another menu can be carried out without pressing the buttons [LOCK], and only digital buttons.
• In service with pressure buttons can enter [-/--] mode BUS OPEN.
When you press the button again, this way out of this mode is done.
* * *
RUBIN 55M06 TV.
Log into the service menu lineup S0.
When pressured the AV to connect the TV's power and hold
Five seconds of it, or at 250-500 ms jumper pins 6 and 7 slots
service. The election option buttons P + or P-, change the value of VOL + or VOL-. Making a memory button TV.
Installation or removal of the regime "hotel"
1.vlezt in the menu (Menu button or the blue button remote)
2. With the remote control to set the background transparent menu bar (see instructions)
3. cursor on the line to set program number
4.nadavit and hold the connect button on the remote covert reception
Teletext before the right corner of the screen lines HOTEL ON / OFF
LOCK mode is turned off without dialing
1. climb in the menu (or pressing the Menu button on the remote the blue button)
2.Install transparent background menu with the remote control (see instructions)
3. cursor to the line set CASTLE
4.nadavit and hold the connect button on the remote hidden teletext reception before the inscription LOCK OFF
NOTE: The line may not have LATCH in the Options menu, if the regime HOTEL connected.
* * *
Modificat anterior de Ashraf Osman joi, 21 iulie 2011 17:15 Modificat de 1 ori
Înapoi sus În jos
Ashraf Othman
Director general
Director general
Numărul de contribuții: 2242
Data înscrierii: 16/06/2010
Vârsta: 53
_______________________________________
Reparatii tv !
tel.0729346286
|
|
